Plaud integration

Overview

Plaud (NotePin S / NotePro) is a third-party recorder integrated into the companion app via Plaud's proprietary iOS "Embedded" SDK. It is an optional second capture path alongside the SATE hardware recorder and the SATE Pendant. A synced Plaud recording is exported as WAV, base64-encoded, and pushed through the exact same upload call the SATE recorder and Pendant use — api.uploadSession() → device-api /sessions → Supabase → the async AI pipeline → recordings. Plaud audio is indistinguishable from SATE audio once it lands: same table, same report, same flag-marker column.

device-lock sensitiveiOS onlyBLE sync onlyCLAUDE.md RULE #1

What makes Plaud different from every other integration in this codebase is risk class:

• SATE recorder: firmware bug at worst loses or delays a recording. Recoverable — reflash, resync, retry.
• SATE Pendant: pure react-native-ble-plx, no native module, no binding concept (CLAUDE.md: "no native rebuild, no binding/lock concern"). Worst case is a dropped BLE session.

:::danger Plaud device-lock Plaud: the device binds to a caller-supplied identity (deviceToken / user_id) at the SDK level. If that identity is inconsistent across binds — e.g. the same physical device gets bound to a different account or a randomly-regenerated identity — the device can become PERMANENTLY LOCKED for that account. There is no firmware to reflash and no server-side undo; the failure mode is a bricked piece of a customer's hardware. This is called out as CLAUDE.md RULE #1, ahead of every other rule in the repo, and this page exists to document it precisely. :::

Because of that, Plaud is the highest-risk integration in the codebase, and the rule in CLAUDE.md is explicit: any change that touches "connect, identity, Keychain, BLE lifecycle, teardown, account/login, provisioning, multi-device, sync, settings" for Plaud must preserve the five invariants below.

Scope today: iOS only, BLE sync only. WiFi Fast Transfer (PlaudWiFiAgent, ~10x faster) is scaffolded (Hotspot entitlement in the config plugin, currently commented out) but not bridged. Android is not supported — Plaud has not released an Android SDK.

Device-lock safety — the 5 invariants

Invariant 1

Stable identity

Invariant 2

Bind guard

Invariant 3

Keychain binding

Invariant 4

No auto-depair

Invariant 5

ACK-before-forget

Source of truth: CLAUDE.md RULE #1, cross-checked against src/plaud/PlaudLink.ts, src/screens/PlaudConnectScreen.tsx, src/screens/PlaudSettingsScreen.tsx, doc/08-plaud.md, and plaud-integration.md. The Swift native module (modules/plaud-sate/ios/PlaudSateModule.swift) is referenced by these docs but its ios/ directory — including the Swift source and the proprietary framework binaries — is not present in this checkout (see Key files below for exactly what is/isn't readable). Claims about native-layer behavior below are sourced from the JS/TS call sites and from doc/08-plaud.md / plaud-integration.md's description of it, not from reading the Swift directly.

1. Stable, account-derived identity — never random, never per-install

// src/plaud/PlaudLink.ts
export function plaudUserId(supabaseUserId: string): string {
  return `sate_${supabaseUserId}`;
}

This exact string is used as:

• the Plaud user_id when minting a token (Cloudflare port, cloudflare/src/functions/mintPlaudToken.ts: body: JSON.stringify({ user_id: \sate_${claims.sub}`, ... })`; the Supabase edge function is documented to do the same — see Backend), and
• the deviceToken argument to PlaudLink.connect(deviceId, plaudUserId) (PlaudConnectScreen.tsx: await plaud.connect(d.id, plaudUserId(userId));).

It is derived from the SATE account id, never randomly generated and never regenerated per install — so a reinstall on the same account reproduces the identical identity string, and a reconnect looks like a reconnect to Plaud's servers rather than a new device claiming the binding. PlaudLink.ts documents the reasoning inline: "Binding the SAME device to a DIFFERENT identity can permanently LOCK it."

2. Bind guard before connect

Before ever calling connect(), the app checks who currently owns the binding and refuses to proceed if it's a different account:

// src/screens/PlaudConnectScreen.tsx, onPickDevice()
const owner = plaud.bindingOwner(d.sn);
if (owner && owner !== userId) {
  setError(
    `This Plaud (SN ${d.sn}) is already linked to another SATE account. ` +
      `Unlink it there first — re-binding it here could lock the device.`
  );
  setPhase("error");
  return;
}

This is the last line of defense before the SDK is asked to bind under a new identity. If the device is unbound or already bound to this account, the flow proceeds to connect() (reconnect, never re-bind). PlaudLink.ts's interface doc pins the contract on connect() itself: "plaudUserId = the account-derived stable identity from plaudUserId(). MUST match what the token was minted for. Never pass a random/changing value."

3. Binding lives in the iOS Keychain, AfterFirstUnlock

// src/plaud/PlaudLink.ts
const bindingKey = (sn: string) => `plaud.bind.${sn}`;
// ...
bindingOwner(sn: string) {
  return PlaudSate!.keychainGet(bindingKey(sn));
}
recordBinding(account: string, sn: string) {
  PlaudSate!.keychainSet(bindingKey(sn), account);
}

The record is plaud.bind.<sn> → account, one key per device serial, stored in the iOS Keychain via the native module's keychainGet/keychainSet/keychainDelete bridge — not AsyncStorage, because AsyncStorage does not survive an app uninstall/reinstall and the Keychain (under AfterFirstUnlock accessibility, per CLAUDE.md RULE #1 item 3) does. This is what makes "reinstall the app, sign back into the same account, reconnect" safe: bindingOwner(sn) still returns the account, so the flow takes the reconnect branch instead of asking the SDK to bind a "new" device.

recordBinding() itself is called immediately after a successful connect() in PlaudConnectScreen.tsx — see Known issues for a gap in that ordering.

4. No auto-depair, ever — teardown is disconnect() only

depair() (the Plaud SDK's unbind primitive, exposed through the native module) is invoked from exactly one place in the JS layer: PlaudLink.resetBinding(), which is itself only called from the explicit UNBIND button in PlaudSettingsScreen.tsx. Every other teardown path — component unmount, navigating away, logout — calls disconnect() only, which drops the BLE link but leaves the Keychain binding and the device's own bound state untouched:

// src/screens/PlaudConnectScreen.tsx — effect cleanup
return () => {
  cancelled = true;
  if (scanning.current) plaud.stopScan();
  // Keep the link alive when heading to Plaud settings — unbind needs it.
  if (!keepConnection.current) plaud.disconnect().catch(() => {});
};

Note the keepConnection ref: navigating from the connect screen into PlaudSettingsScreen (to unbind) deliberately skips even the disconnect() call, because the settings screen's unbind flow needs the device still connected — see invariant 5.

CLAUDE.md states the rule directly: "Unmount/teardown/logout must only disconnect()... never depair."

5. ACK-before-forget on unbind

Unbinding is a distributed delete across two independently-failable parties (the phone, the device over BLE) and the order is fixed: send depair → wait for the device's ACK → only then delete the local Keychain record. Deleting the local record first would leave the device convinced it's still bound while the app has forgotten it — a desync that, per the docs, causes the device to freeze to protect its data.

// src/plaud/PlaudLink.ts — NativePlaudLink.resetBinding()
async resetBinding(sn: string) {
  // ACK-before-forget: depair() resolves ONLY after the device confirms
  // the unbind (bleDepair callback; native layer refuses when disconnected and
  // times out instead of hanging). If it throws, the Keychain record is KEPT
  // — deleting local state before the device ACKs desyncs the binding and
  // can freeze the device.
  await PlaudSate!.depair();
  PlaudSate!.keychainDelete(bindingKey(sn));
  // Forget the remembered device too, so it won't auto-reconnect after unbind.
  this.forgetDevice(sn);
}

PlaudSettingsScreen.tsx's doUnbind() calls resetBinding and only calls disconnect() after it resolves, and on failure keeps the Keychain record and tells the user explicitly:

// src/screens/PlaudSettingsScreen.tsx
try {
  await plaud.resetBinding(sn);
  await plaud.disconnect().catch(() => {});
  setDone(true);
} catch (e: any) {
  setError(
    (e?.message ?? "Unbind failed") +
      "\n\nThe binding was NOT removed. Keep the device nearby and connected, then try again."
  );
}

Per CLAUDE.md and doc/08-plaud.md, the native module enforces the safety side of this contract: depair is refused while disconnected (can't send a command with no link), fails fast on a mid-command BLE drop rather than hanging, and times out after 20s instead of hanging forever — all so resetBinding gets a definite success/failure rather than an ambiguous state. This native-layer behavior is described in the docs and in CLAUDE.md; it could not be verified directly against PlaudSateModule.swift because that file is not present in this checkout (see the note at the top of this section).

Not a hardware-proven guarantee. plaud-integration.md and doc/08-plaud.md both flag this candidly: Plaud's own docs say "a device can only be bound to one application at a time" and "binding is tied to app installation — unbind before uninstalling" — but iOS gives apps no uninstall hook, so an unbind-before-delete can never be forced. The five invariants make a same-account reinstall safe iff Plaud's backend treats a re-bind with the same user_id as idempotent, which Plaud has not confirmed in writing. If a device does end up bound to a dead install, resetBinding (depair) is the user-initiated recovery path.

Connection lifecycle

Connect (PlaudConnectScreen.tsx):

1. Mint a Plaud user token via api.getPlaudToken() (sateApi.ts), then plaud.initSdk(token). A ~2s delay follows before startScan() — the RSA key exchange inside initSdk is async and, per an inline comment, scanning before it lands "fires before the SDK is actually ready and finds nothing" (confirmed on-device: the app's startScan() log printed before the SDK's own "RSA key pair obtained and stored" log).
2. startScan() streams found devices via the onScanResult event. If a targetSn was passed in (reconnecting a specific already-paired device from Home), the scan callback auto-fires onPickDevice the moment that serial appears — but only if plaud.bindingOwner(d.sn) === userId (invariant 2 applied again at the auto-connect path, not just the manual-pick path).
3. onPickDevice(d) runs the bind guard (invariant 2), then connect(d.id, plaudUserId(userId)) (invariant 1), then — on success — recordBinding(userId, d.sn) (invariant 3) and rememberDevice(d.sn, d.name) (a separate, non-safety-critical "known devices" list used to show a reconnect UI on next app open, distinct from the binding record).
4. listFiles() populates the recordings list; the user picks a patient and either syncs manually or leaves auto-upload on.

Capture: recording can be driven from the app (startRecord()/stopRecord()) or from the physical button on the Plaud device — both surface through the same onRecordState event subscription, so the UI doesn't care which triggered it. Flag markers (physical taps on the Plaud during a take) are polled — not pushed — by the native layer (onMark event) and rendered live in PlaudConnectScreen; see doc/08-plaud.md §"Flag markers" for the low-level BleAgent/bleMarking mechanics (a documented best-effort hack around a gap in the supported PlaudDeviceAgent wrapper — unverified unit, see Known issues).

Disconnect vs. depair: disconnect() drops only the BLE link; the Keychain binding and the device's bound state are untouched, and reconnecting later needs no re-bind. depair() is the SDK's actual unbind primitive and is reachable only through resetBinding() from the explicit UNBIND button (invariants 4 and 5). These are not interchangeable, and no code path outside PlaudSettingsScreen's confirmed UNBIND flow should ever call depair/resetBinding.

Shared-radio handoff. Per CLAUDE.md RULE #2, three BLE stacks compete for the phone's one radio: SATE and the Pendant share a single react-native-ble-plx BleManager (src/ble/bleManager.ts), but the Plaud SDK owns its own CBCentralManager and needs the radio exclusively. The handoff into Plaud is a hard teardown of the shared manager — link.teardown() → destroySharedBleManager() — and it is rebuilt lazily the next time SATE or the Pendant needs it. This is explicitly not the same as the SATE↔Pendant handoff, which must never destroy the shared manager (destroying and recreating a ble-plx BleManager leaves scans returning zero devices with no error). src/ble/radio.ts is documented as the sole arbiter of this handoff (logical owners autosync | sate-fg | pendant | plaud), and CLAUDE.md is explicit that the Plaud radio release only ever calls disconnect(), never depair() — i.e. the radio handoff and the device-lock invariants are orthogonal and the former must never leak into the latter.

Backend

Plaud has no dedicated backend path — it reuses the device-agnostic parts of the existing SATE upload pipeline:

mint-plaud-token — mints a per-user, ~24h Plaud "User Access Token" server-side so the Plaud partner credentials (PLAUD_CLIENT_ID / PLAUD_API_KEY or PLAUD_CLIENT_SECRET) never reach the phone. Two-step Plaud OAuth (partner token via HTTP Basic, then a user token scoped to user_id: sate_<uid>). Deployed with --no-verify-jwt — per CLAUDE.md, this and device-api validate the caller's Supabase JWT themselves, and redeploying with Supabase's MCP default (verify_jwt:true) breaks token minting.

The Supabase edge function's source (react_app_sate-ui_update/supabase/functions/mint-plaud-token/, as referenced by plaud-integration.md and doc/08-plaud.md) is not present in this checkout — only device-api and process-device-session exist under react_app_sate-ui_update/supabase/functions/. It is documented as deployed in production. A parallel, disabled-by-default port exists at cloudflare/src/functions/mintPlaudToken.ts for the separate Cloudflare-backed stack; it returns HTTP 501 unless env.PLAUD_ALLOW_MINT === '1', because that stack has its own users table with a different uuid space, so sate_<cloudflare_uid> would differ from sate_<supabase_uid> for the same human — i.e. enabling it naively would violate invariant 1 by presenting a different identity to a device already bound under the Supabase identity. The guard comment in that file spells out exactly the three conditions (clean-slate fleet / matching uuid seeding / Plaud-confirmed re-bind semantics) required before flipping it on.

device-api POST /sessions — the upload endpoint. Unlike a SATE recorder, which authenticates with its own per-device key (sate_devices row), Plaud has no device row at all — a Plaud recording is uploaded under the signed-in user's own Supabase JWT ("USER-authed" per CLAUDE.md). From react_app_sate-ui_update/supabase/functions/device-api/index.ts:

// User-authenticated session upload. The SATE recorder POSTs with its
// device key (handled earlier), but the phone app uploads on behalf of a
// device that has NO device key of its own — a Plaud recorder (which is
// never registered in sate_devices), or a BLE-bridged SATE session. Here
// the caller is the signed-in user, so the session is stored under user.id.
if (subPath === '/sessions' && method === 'POST') {
  const body = await req.json();
  const { wav_base64, ...meta } = body;
  const wavBytes = Uint8Array.from(atob(wav_base64 || ''), (c) => c.charCodeAt(0));
  return await storeSessionRecord(supabase, user.id, {
    device_serial: meta.device_serial || 'plaud',
    patient_id: meta.patient_id || 'PT',
    session_number: meta.session_number || 0,
    sample_rate: meta.sample_rate || 16000,
    flags: Array.isArray(meta.flags) ? meta.flags.filter((n: unknown) => Number.isFinite(n)) : undefined,
  }, wavBytes);
}

device_serial is sent by the app as plaud-<sn> (PlaudConnectScreen.tsx's uploadOne: device_serial: \plaud-${sn}`), so Plaud sessions are distinguishable from SATE-recorder sessions in sate_devices/recordingswithout any schema change.device-apiitself is deployedverify_jwt:false(same reasoning asmint-plaud-token— it validates the token itself). From/sessionsthe flow is unchanged from a SATE upload:storeSessionRecord→ device-sessions bucket → the async Cloudflare-container processing pipeline →finalize-session→recordings`.

Key files

File	Role	Present in this checkout?
CLAUDE.md (RULE #1)	The 5 invariants, canonical statement	Yes
src/plaud/PlaudLink.ts	JS interface + NativePlaudLink (real) + MockPlaudLink (simulator/dev); identity (plaudUserId), Keychain bindings, resetBinding (ACK-before-forget)	Yes
src/screens/PlaudConnectScreen.tsx	Connect/scan/sync UI; bind guard on onPickDevice; owns the connect lifecycle and shared-radio effect cleanup	Yes
src/screens/PlaudSettingsScreen.tsx	The UNBIND button; ACK-before-forget flow via resetBinding then disconnect	Yes
src/components/PlaudDeviceCard.tsx	Device art/graphic for the connect/settings UI	Yes
src/api/sateApi.ts	getPlaudToken() — calls the mint-plaud-token edge function	Yes
modules/plaud-sate/index.ts	requireNativeModule("PlaudSate") wrapper; PlaudSateNative interface (initSdk, connect, depair, keychainGet/Set/Delete, ...); isPlaudAvailable() fallback gate	Yes
modules/plaud-sate/app.plugin.js	Expo config plugin: Info.plist keys (local network / location, for WiFi Fast Transfer) survive expo prebuild; Hotspot entitlement present but commented out (not yet wired)	Yes
modules/plaud-sate/expo-module.config.json	Expo local-module manifest	Yes
modules/plaud-sate/ios/PlaudSateModule.swift	Swift native bridge: scan/connect/depair/listFiles/exportWav/deleteFile, ACK enforcement, Keychain bridge	No — modules/plaud-sate/ios/ does not exist in this checkout. Referenced only in docs/comments.
modules/plaud-sate/ios/PlaudSate.podspec	Vendors the 3 proprietary Plaud frameworks + bundle	No — same as above.
modules/plaud-sate/ios/Frameworks/ (PlaudBleSDK.framework, PlaudWiFiSDK.framework, PlaudDeviceBasicSDK.framework + .bundle)	Proprietary SDK binaries	No — git-ignored (.gitignore: modules/plaud-sate/ios/Frameworks/), copied in per-machine from a separate plaud-sdk-public repo per plaud-integration.md.
react_app_sate-ui_update/supabase/functions/device-api/index.ts	POST /sessions (user-authed, no device key)	Yes
react_app_sate-ui_update/supabase/functions/mint-plaud-token/	Supabase edge fn minting the per-user Plaud token	No — not present in this checkout, documented as deployed in prod.
cloudflare/src/functions/mintPlaudToken.ts	Cloudflare-stack port of the above; disabled by default (PLAUD_ALLOW_MINT) pending uuid-space reconciliation with Supabase	Yes
plaud-integration.md (repo root)	Deep-dive build doc: setup steps, open questions to confirm with Plaud, verification checklist	Yes
doc/08-plaud.md	Numbered handbook chapter: safety summary, sync flow, flag-marker mechanics (BleAgent/bleMarking hack)	Yes

Known issues & current status

All items below are sourced from the project's stuck-state audit memory (~/.claude/projects/-Users-longcao-Desktop-SATE/memory/stuck-state-red-flags.md, dated 2026-07-22) and cross-checked against the current source. None of these break the 5 invariants outright, but they are gaps worth knowing before touching this code.

Issue	Symptom	File	Status
recordBinding() is written after connect() resolves	Between a successful connect() and the following recordBinding(userId, d.sn) call, there is a window where the SDK-level bind has happened but the Keychain record hasn't been written yet. If the app is killed or crashes in that window, the device ends up SDK-bound to this account but the app's own bind guard (bindingOwner(sn)) doesn't know it — a subsequent connect attempt (e.g. by another account, or after a botched state) would not see this account as the owner and could attempt a re-bind under a different identity, risking invariant 1.	src/screens/PlaudConnectScreen.tsx, onPickDevice(): await plaud.connect(...) then plaud.recordBinding(...) on the next line	OPEN — a lock-guard gap window, not yet closed.
Plaud connect effect's [api, plaud] dependency array causes teardown mid-sync	The main connect useEffect in PlaudConnectScreen.tsx depends on [api, plaud]; if either identity changes while a sync is in flight (e.g. a plaud link instance is recreated upstream), the effect's cleanup fires — which calls plaud.stopScan() and, unless keepConnection.current is set, plaud.disconnect() — potentially interrupting an in-progress upload or scan.	src/screens/PlaudConnectScreen.tsx, the connect effect and its cleanup	OPEN — teardown-mid-sync risk from the effect dependency shape.
markOffsets unit is unverified	PlaudExportResult.markOffsets / PlaudSyncedFile.markOffsets are assumed to be millisecond offsets (matching SATE's own flags convention), and PlaudConnectScreen's fmtOffset() formats them as such — but this is explicitly flagged as unconfirmed. doc/08-plaud.md details that marking isn't part of the supported PlaudDeviceAgent API at all; the native module reaches into the low-level BleAgent (bleMarking / bleGetRecordMarkingTags) as a best-effort, unsupported hack, and doesn't know for certain whether the NotePin/NotePro reports ms offsets, seconds, or absolute unix-timestamps (the 3.0 path assumes absolute unix-seconds and computes (timestamp - sessionId) * 1000).	modules/plaud-sate/index.ts (PlaudExportResult.markOffsets doc comment: "UNVERIFIED unit... check on a real device before display"); src/plaud/PlaudLink.ts (PlaudSyncedFile.markOffsets doc comment references the same caveat); src/screens/PlaudConnectScreen.tsx fmtOffset()	OPEN — needs an on-device rebuild + log verification (doc/08-plaud.md describes tapping the Plaud at a known point and reading the native module's [PlaudSate] bleMarking … logs to confirm).

Two related but lower-severity open items, not part of this page's 3 headline issues but worth noting for anyone working nearby: doc/08-plaud.md flags that marking support itself is a hack around a gap in the supported SDK surface (worth asking Plaud to expose officially), and plaud-integration.md lists two standing open questions for Plaud about re-bind idempotency and the internal ordering of depair's own key deletion relative to the device ACK — both bear directly on invariants 1 and 5 and are flagged as not yet answered by Plaud.
